Model Name

Indoor: HSU-19CleanCool(INV)(Pro)

Outdoor: HSU-19K(INV)(Pro):ODU

Category: Inverter

Series: Inverter

Capacity and Parameters

Type: Inverter

Ton Range (TR): 1.6 Ton

Capacity(BTU): 19000

Rated Cooling Capacity (W): 5250

Rated Heating Capacity (W): /

Rated Power Input Cooling (W): 1800

Rated Power Input Heating (W): /

Max. Power input Cooling (W): 1860

Max. Power input Heating (W): /

Energy Effeciency Ratio (EER): 2.93

Seasonal Energy Efficiency Ratio (SEER):: 3.80

Coefficient of Performance (COP): /

Rated Running Current (A) Cooling: 8.0

Rated Running Current (A) Heating: /

Max.Running Current (A) Cooling: 9.0

Max.Running Current (A) Heating: /

Power supply (Ph,V,Hz): 1/230/50HZ

Air Circulation (m3/h): 1100

Moisture Removal (10-3m3/h): /

Refrigerant Type: R32

Refrigerant Standard (Kg): 0.980

Refrigerant Pipe Liquid Side Diameter (mm): 6

Refrigerant Pipe Gas Side Diameter (mm): 12

Compressor Type: Rotary

Evaporator/Condenser: 100% 7mm Grooved Copper

Heat Exchangers: Golden Fin

Indoor

Indoor Net dimension (mm) W/D/H: 975*220*318

Indoor Package dimension (mm) W/D/H: 1050*397*301

Indoor Net weight (kg): 12.5

Indoor Gross weight (kg): 14

Indoor Sound power level [dB(A)] Hi/Mid/Lo: 47/43/40

Outdoor

Outdoor Net dimension (mm) W/D/H: 800*280*553

Outdoor Package dimension (mm) W/D/H: 908*405*625

Outdoor Net weight (kg): 32.5

Outdoor Gross weight (kg): 35.5

Outdoor Sound power level [dB(A)] Hi/Mid/Lo/So: 55

Air Flow Direction

Up & Down: Auto

Left & Right: Auto

User Functions

Wifi:: No

UVC Technology:: No

Energy Savings:: Yes (Up to 65%)

Dry Mode:: Yes

Self Clean:: Yes

ECO Mode:: Yes

Turbo Function:: Yes

Auto Restart Function:: Yes

Sleep Mode:: Yes

Low Noise:: Yes

Timer:: Yes

Quick & Easy Installation:: Yes

Child Lock:: Yes

Warranty

Compressor (Yrs): 12

Spare Parts and Components (Yrs): 4

Service (Yrs): 2
